Vehicle Fire Exposure Test Device
The test system is used for burning the whole vehicle. Test space can be customized accordingly.
LPG External Fire Exposure Test Machine
It meets standards of ECE R100 and UL2580.
-Model: BE-8202-3000
-Test Space: W1500*D2500*H1000mm (Can be customized)
-External Dimension: W7500*D3700*H960mm
-Max. Load: 1000KG (2000KG and 3000KG can be customized)
-Combustion nozzle spacing: ≤75mm
-LPG combustion control: Proportional control valve intake flow
-Weight: About 3.5T
-Power Source: 380V, 50Hz, 7KW
-Mode of control: PLC+ touch screen close adjustment combined with computer remote control
-Medium of Combustion: LPG (provided by customer)
-Others: Monitoring system with camera
-Control software (Can be customized)
External Fire Exposure Test Machine
It meets standards of ECE R100 and UL2580.
-Test Space: W1500*D2500*H800mm or W2000*D3000*H1000mm
-Equipment Dimension: W7500*D3700*H960mm or W8500*D4200*H960mm
-Movable Rack W1500*D3000mm or W2200*D3200mm
-Max. Load: 1000KG (2000KG,3000KG can be customized)
-Object Holder Moving Speed: 6000mm/min (Adjustable)
-Refractory Rack Moving Speed: 6000mm/min (Adjustable)
-Control System: PLC touch screen close control + computer remote control
-Ignition Mode: Automatic high pressure pack ignition
-Medium of Combustion: Gassoline
-Effective Test Space: W300*D300*H300mm
-Overall Dimension: W1270*D1600*H1890mm
Battery Projectile Tester
-Force (T) : 20/50
-Structure: Horizontal
-Crsuh Method: Horizontal
-Drive Mode: Electro-hydraulic servo
-Test Space: W800*D800*H800mm or W1000*D1000*H1000mm (can be customized on request)
-Power Supply Voltage: AC380V 50Hz
-Crush Speed: 1-400mm/min
Battery Projectile Tester (Open type)
It meets the projectile test of UL1642.
-Burner: Bunsen burner
-Flame Applicate Time: 0～9999H, M, S (Settable)
-Flame Height: Adjustable.
-Fire Ignition Device: Automatic ignition / flameout (remote control control is effective within 8 meters)
-Control Mode: Remote Control
-Burning Gas Requirement: Methane（Customer Prepares）
-Overall Dimension: W1050*H700*D1050 mm (For reference, please refer to the final design drawing)
-Weight About: 80KG
-Power Source: AC220V, 50Hz. 1.0KW
